More convenient operation and chip removal, low resistance, high rigidity, short processing time, high efficiency, excellent heat dissipation, and more stable operation.
Product Specifications
| Item | Unit | CNC36C | CNC46C |
| Max.Swing Diameter | mm | Φ400 | Φ400 |
| Max Process Diameter | mm | Φ400 | 中400 |
| Max Process Length | mm | 220 | 220 |
| Spindle Nose | – | A2-4 | A2-5 |
| Spindle Speed | r/min | 0-4500(Factory Setting) | 0-4500(Factory Setting) |
| Spindle Bore | mm | φ46 | φ56 |
| Spindle Motor Power | kw | 5.5 | 7.5 |
| Tool Installation | – | Gang type | Gang type |
| Max.number of Tools | pcs | 8 | 8 |
| X/Z Axis Effective Travel | mm | 750/280 | 750/280 |
| X/Z Axis Motor Power | kw | 0.85/1.3 | 1.3/1.3 |
| X/Z axis repeatability | mm | ±0.005 | ±0.005 |
| Chuck Size | inch | 5″ | 6″ |
| Max.passable Bar Diameter | mm | φ35 | φ45 |
| X/Z Axis Machining Travel | mm | 720/250 | 720/250 |
| Center Height | mm | 56 | 56 |
| Square Tool Holder | mm | 20×20 | 20×20 |
| Round Hole Tool Holder | mm | φ20 | φ20 |
| X/Z Axis Fast Moving Speed | m/min | 26/26(Factory Setting) | 26/26(Factory Setting) |
| Machine Power | kw | 10 | 12 |
| Net Weight | kg | 2800 | 2900 |
| Machine Dimensions(L×W×H) | mm | 2200×1350×1760 | 2200×1350×1760 |
| Packing Dimensions(L×W×H) | mm | 2300×1500×2100 | 2300×1500×2100 |
